We recognize that there is an ever-growing demand for steel products, not only in the Middle East, but throughout the entire world. As a result, the AL ITTEFAQ STEEL PRODUCTS CO. (ISPC) has embarked on several expansion programs to further consolidate our position as a trusted brand in the steel industry and as a manufacturer of high-quality steel products. One of these expansion programs is the ARAB STEEL CO.

The ARAB STEEL CO. is a flagship company of the AL ITTEFAQ STEEL CO. and is already setting up a green-field and integrated steel plant with a capacity limit of up to 4.5 million tons. The ARAB STEEL CO. is set up in the prime location of Dammam, which is the second industrial area in the Kingdom of Saudi Arabia. The venture will be actualized in three phases, making it the largest private-sector steel project in the Middle East.

The ARAB STEEL CO. will be a showcase of modern-day innovation, a prime example of integrated steel manufacturing spread over an area of 3.3 million square meters. The use of world-class DRI, Billets, Plates, Hot Rolled Coils and Hot Rolled-Skin Passed Coils means that every process will be undertaken at maximum efficiency, resulting in very competitive rates for our products.

The plant is deliberately and strategically located in the second Industrial City of Dammam-KSA, which is close to the captive port that opens into the Arabian Sea. In addition, it is well connected by roads, another positive aspect of its key location. The ARAB STEEL CO. will have only the best infrastructure to support its manufacturing processes.

Technological Edging Features & Advantages:

  • Twin Shell EAF
  • DC EAF
  • Use of Maximum DRI in Charge-Mix
  • Use of High Carbon DRI
  • Hot DRI Feeding
  • Bottom Bubbling in EAF
  • Oxy-Fuel Burners
  • Twin Station LF
  • Vacuum Tank Degasser
  • In-Line Strip Production (ISP)
  • Hot Skin-Pass Mill

Planned Production After Completion:

  • Hot Rolled Coils 1.2 MTPA
  • Plates 0.8 MTPA
  • Billets 2.5 MTPA

The ARAB STEEL CO. produces only the finest-quality Hot Rolled Coils and Hot Rolled-Skin Pass Coils.

HRC for cold rolling and drawing application JIS G3131SPHC / SPHD / SPHE
Cold Rolled & Galvanized SAE 1008, DIN 1614 STW 24,SAE 1006, DIN 1614 STW23
Extra Deep Drawing IS 11513 EDD
Boiler Quality ASTM A516 70, JIS G3103 SB410, ASTM 285 GRB, JIS G3118 SGV410
LPG Grade JIS 3116 (SG255),ASTM 621, ASTM 622
Petroleum Pipes API 5L GRB,API 5L X42,API 5L X56,API 5L X60 API 5L X65,API 5L X70
Structural Grades JIS G3101 SS400,DIN 17100 St 44-2, DIN 17100 St44-3, DIN 17100 St5203,ASTM 570 Gr 50, ASTM 560 Gr 36
Corten Steel JIS G3125 (SPAH)
Tubes & Pipes JIS G3132 SPHT1,JIS G3131 SPHC,API5L X42
Automobiles EN10149-2 S350MC,EN10149-2 S500MC
Electrical Steel DIN 1614 Pt1-St22, DIN 1614 Pt1-RSt23, SAE 1008
Medium and High Carbon Steel SAE 1020, ASTM 515
Width Range 800 - 1350 mm
Thickness Range 1.0 - 12.7 mm
Coli Weight 24 tons max.
Skin Pass Facility Hot Skin Pass Mill Facility Available
Packing As per customer specification
